Name: Server Technology PRO2 Smart POPS PDU C2LG36TE-YQME2M66 - Link - power distribution unit expansion module (rack-mountable) -
SKU: 321639

Product Details ＋

Server Technology PRO2 Smart POPS PDU C2LG36TE-YQME2M66 - Link - power distribution unit expansion module (rack-mountable) - AC 208 V - 17.3 kW - 3-phase WYE (star) - Ethernet 10/100, RS-232 - input: IEC 60309 3P N G - output connectors: 36 (24 x IEC 60320 C13, 12 x IEC 60320 Cx)

Network monitoring
The PRO2 hot-swappable network card provides for HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
Hot-swap network card
Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit.
Star multi-linking
PRO2 provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
Temperature/humidity monitoring
PRO2 Master and Link units each support two external 10' (3m) T/H probes. Receive SNMP-based alerts and email notifications.
Auto-flip current display
Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
Per-inlet power sensing
Meets ANSI C12.1 for billing-grade accuracy of current per phase. PIPS includes voltage, active power, apparent power, power factor, and energy.
Branch current monitoring
PRO2 monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
Branch circuit protection
PRO2 meets the UL and IEC 60950-1 requirement for branch circuit protection through use of UL489 rated magnetic-hydraulic circuit breakers or UL248 fuses.
Alternating phase
3-phase power is wired in an alternating fashion per outlet for simplified load balancing, reduced cord lengths, and better airflow.
High retention outlets
PRO2 receptacles have high retention and are compatible with P-Lock type power cords.
High temperature rating
This product has been tested and approved for safe and reliable operation in 60°C (140°F) data center environments.

The Server Technology PRO2 POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS and POPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output.
